Rhombus Housings

These rhombus housings are commonly used in specific machinery designs, to provide a diamond-shaped bearing mounting footprint.

12 products

Loading filters…

Rhombus Housings

What is a rhombus housing?

A rhombus housing is a two-bolt flange bearing housing with a diamond-shaped (rhombus) flange, designed to bolt a shaft support onto a vertical surface such as a machine side plate or frame. Rhombus housings are usually made from ductile cast iron, which is stronger and tougher than standard grey cast iron. This lets the housing be made slimmer and lighter while still carrying the load, so it suits compact machines where space and weight matter.

A standard rhombus housing unit is made up of:

  • A diamond-shaped flange housing in ductile cast iron, with a bolt hole at each end
  • A self-aligning insert bearing, seated in a spherical bore in the centre of the housing
  • A locking method, usually grub screws, that fixes the insert to the shaft
  • Seals on the insert bearing, and a grease nipple for relubrication.

The ductile iron housing is what sets a rhombus unit apart.

  • Ductile iron, also called spheroidal graphite cast iron, is less brittle than standard cast iron and better able to cope with shock and vibration.
  • Its extra strength allows a thinner, more compact flange, so the unit takes up less space along the shaft and weighs less.

Rhombus housings are available as complete units with the insert fitted, or as housings on their own.

Why are rhombus housings essential?

They give a strong, compact two-bolt shaft support in places where a standard flange would be too bulky or too heavy. The slim diamond shape fits on narrow frames and side plates, and the ductile iron housing copes better with knocks, shocks, and vibration than a standard cast iron flange of a similar size.

As with other insert bearing housings, the spherical seat lets the bearing align itself as it is bolted down, so it copes with small errors between the housings at each side of a machine. They come in standard metric and inch sizes, so replacements are easy to source.

Typical applications include:

  • Compact conveyors and roller drives
  • Agricultural machinery and implements
  • Packaging and labelling machines
  • Fans and blowers
  • Food processing machinery
  • Printing and textile machinery
  • Light-duty material handling equipment
  • Mobile and vehicle-mounted equipment, where weight matters

The main types of rhombus housings

  • Ductile cast iron rhombus units - The standard design, with a slim, diamond-shaped ductile iron flange and a grub screw locking insert. They are compact, light, and resistant to shock.
  • Rhombus units with eccentric collar inserts - These use an insert that locks to the shaft with an eccentric collar, which grips without marking the shaft. They suit drives that run in one direction.
  • Rhombus units with covers - Some units can be fitted with an open or closed cover, for extra protection from dirt and water, or to guard the end of a shaft.
  • Metric and inch bore units - Rhombus units are available for both metric and inch shafts, usually in the same housing size for each series.

How to choose the right rhombus housing?

  • Shaft size - Match the insert bearing bore to the shaft, and check whether the shaft is metric or inch.
  • Bolt centres and bolt size - Check the distance between the two bolt holes and the bolt size suit the frame. For example, a UCFE205 has 99mm bolt centres and takes M14 bolts.
  • Space - Check the overall length and width of the flange, and the thickness of the unit along the shaft, fit the space available. Rhombus units are often chosen because they are slimmer than other flange types.
  • Load and duty - Rhombus units suit light-to-medium loads. For heavier loads, consider a square four-bolt flange or pillow block.
  • Locking - Grub screws suit most applications. Choose an eccentric collar insert if the shaft must not be marked and the drive runs in one direction.

Essential references and specialised ranges

How the numbering works:

Rhombus unit references combine the insert bearing and the housing:

UC = insert bearing with grub screw locking and an extended inner ring

FE = two-bolt rhombus flange housing in ductile cast iron

The digits = the series and bore code. Multiply the last two digits by five to get the bore in mm.

Examples:

UCFE204 = rhombus flange unit for a 20mm shaft

UCFE205 = rhombus flange unit for a 25mm shaft

FE205 = the rhombus housing on its own, which takes a UC205 insert

Inch bore units add a suffix showing the bore in sixteenths of an inch, so a UCFE205-16 fits a 1 inch shaft.

Suffixes:

-14, -15, -16 and similar = inch bore in sixteenths of an inch

E = eccentric collar locking insert

Some manufacturers add their own suffixes for seal types, covers, or design versions. Suffix codes vary between manufacturers, so check the supplier’s catalogue for the exact meaning.

FAQ - All you need to know about rhombus housings

What is the difference between a rhombus housing and an oval housing?

Both are two-bolt flange housings. A rhombus housing has a diamond-shaped flange and is usually made from ductile cast iron, which makes it stronger for its size and allows a slimmer, lighter design. An oval housing has a rounded oval flange and is usually made from standard cast iron. Some manufacturers use the names differently, so check the reference and dimensions when replacing a unit.

What is ductile cast iron?

Ductile cast iron, also called spheroidal graphite or SG iron, is a type of cast iron with graphite in rounded nodules rather than flakes. This makes it tougher and less likely to crack under shock or vibration than standard grey cast iron.

Can a rhombus unit replace an oval flange unit?

Sometimes, but not always. The bolt centres, bolt size, and overall dimensions may be different, even for the same shaft size. Always compare the dimensions before swapping one type for another.

Do rhombus housings need lubrication?

The insert bearing is supplied greased, and most units have a grease nipple for relubrication. Regrease regularly in dusty, wet, or hot conditions, adding grease slowly until fresh grease just appears at the seals.

How do I fit a rhombus housing?

Slide the unit onto the clean, burr-free shaft and fit the two bolts. Tighten them evenly so the flange sits flat against the frame, then lock the insert to the shaft once both ends of the shaft are bolted down and it turns freely.

How do I identify a rhombus housing I need to replace?

The reference is usually cast on the housing and marked on the insert bearing. If it cannot be read, measure the shaft diameter, the distance between the bolt hole centres, the bolt hole size, and the overall length, width, and thickness of the housing.

What are the signs that a rhombus housing needs replacing?

Look out for:

  • Grinding, squealing, or rumbling from the bearing
  • More vibration than normal
  • The housing running hot
  • Play in the shaft
  • Grease leaking past the seals
  • A cracked flange or loose bolts
  • The shaft slipping in the insert bearing
