SKU: 08B-2-SYNO-10FT-RENOLD
Renold SYNO 08B-2 BS Duplex Roller Chain 1/2 inch Pitch - 10 Feet Length
Renold SYNO 08B-2 BS Duplex Roller Chain 1/2 inch Pitch - 10 Feet Length
Regular price
€986,81
ex VAT
Regular price
Sale price
€986,81
ex VAT
Equivalent to: SNX08B-2
In stock
Price Break
10+
€878,26
19+
€828,92
29+
€819,05
39+
€809,18
49+
€799,32
74+
€789,45
99+
€740,11
199+
€730,24
249+
€720,37
499+
€710,50
999+
€690,77
Couldn't load pickup availability
Description
Description
Renold SYNO Maintenace-free Corrosion-resistant Duplex Chain: Renold Syno Nickel Plated chain is ideal for situations where lubricant is to be avoided. Particularly in hygiene-sensitive applications. With a food industry-approved lubricant contained within its sintered bush, this chain needs no relubricating in practically every environment. The roller coating, unique to Renold, is especially suited to the food industry.
Equivalent: SNX08B-2
- Brand / Quality:
- Renold - High Quality
- Pitch:
- 12.7mm = 0.5 (1/2) inch
Technical
Technical
| Pitch (A) | 0.5 inch |
|---|---|
| Pitch (A) | 12.7mm |
| Inside Width min (B) | 7.75mm |
| Roller Diameter max (C) | 8.51mm |
| Plate Height max (D) | 11.7mm |
| Plate Width Inner max (E) | 1.55mm |
| Plate Width Outer max (F) | 1.55mm |
| Pin Diameter max (G) | 4.45mm |
| Pin Length max (H2) | 30.4mm |
| Connecting link extension max (J) | 2mm |
| Transverse Pitch nom (K) | 13.92mm |
| ISO606 Tensile strength min | 31100 N |
| Weight | 1.38 kg/m |
