SKU: 22222-E1-Ku-FAG
FAG 22222E1K X-life Spherical Roller Bearing with AHX3122 Withdrawal Sleeve 105x200x53mm
FAG 22222E1K X-life Spherical Roller Bearing with AHX3122 Withdrawal Sleeve 105x200x53mm
Regular price
€447,63
ex VAT
Regular price
Sale price
€447,63
ex VAT
In stock
Price Break
3+
€340,91
4+
€321,76
9+
€317,93
19+
€314,10
29+
€310,27
39+
€306,44
49+
€287,29
59+
€283,46
249+
€279,63
499+
€275,80
999+
€268,14
Description
Description
- Brand / Quality:
- FAG - High Quality
- Inside Diameter:
- 105mm
- Outside Diameter:
- 200mm
- Width:
- 53mm
- Seals / Shields:
- None
- Clearance:
- * Standard
Technical
Technical
| d1H | 105mm |
|---|---|
| d | 110mm |
| D | 200mm |
| B | 53mm |
| r min | 2.1mm |
| D1 | 178.7mm |
| d2 | 129.4mm |
| ds | 4.8mm |
| ns | 9.5mm |
| a | 4mm |
| b | 11mm |
| Thread d2G | M120X2 |
| l | 68mm |
| da min | 122mm |
| Da max | 188mm |
| ra max | 2.1mm |
| Dynamic load Cr | 550000 N |
| Static load C0r | 600000 N |
| e | 0.25 |
| Y1 | 2.71 |
| Y2 | 4.04 |
| Y0 | 2.65 |
| Fatigue load limit Cur | 62000 N |
| Limiting speed nG | 4000 rpm |
| Reference speed nB | 3000 rpm |
| Bearing weight | 6.82 kg |
| Withdrawal sleeve weight | 0.774 kg |
