SKU: 23026-E1A-K-M-C3u-FAG

FAG 23026E1AKMC3 X-life Spherical Roller Bearing with AHX3026 Withdrawal Sleeve 125x200x52mm

Name: FAG 23026E1AKMC3 X-life Spherical Roller Bearing with AHX3026 Withdrawal Sleeve 125x200x52mm
Brand: FAG
SKU: 23026-E1A-K-M-C3u-FAG
Price: 667.99 EUR
Availability: InStock

€667,99 ex VAT

Sale Sold out

In stock

Price Break

3+ €508,74

4+ €480,16

9+ €474,44

19+ €468,73

29+ €463,01

39+ €457,30

49+ €428,72

59+ €423,00

249+ €417,28

499+ €411,57

999+ €400,13

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: FAG - High Quality
Inside Diameter:: 125mm
Outside Diameter:: 200mm
Width:: 52mm
Seals / Shields:: None
Clearance:: * Standard

Technical

d1H	125mm
d	130mm
D	200mm
B	52mm
r min	2mm
D1	182.3mm
ds	4.8mm
ns	9.5mm
a	4mm
b	14mm
Thread d2G	M140X2
l	67mm
da min	138.8mm
Da max	191.2mm
ra max	2mm
Dynamic load Cr	540000 N
Static load C0r	730000 N
e	0.23
Y1	2.95
Y2	4.4
Y0	2.89
Fatigue load limit Cur	70000 N
Limiting speed nG	3600 rpm
Reference speed nB	2600 rpm
Bearing weight	5.7 kg
Withdrawal sleeve weight	0.916 kg
