SKU: 51112-SKF
SKF 51112 Single Thrust Ball Bearing 60x85x17mm
SKF 51112 Single Thrust Ball Bearing 60x85x17mm
Regular price
€39,21
ex VAT
Regular price
Sale price
€39,21
ex VAT
In stock
Price Break
10+
€29,86
19+
€28,18
29+
€27,85
39+
€27,51
49+
€27,17
74+
€26,84
99+
€25,16
199+
€24,83
249+
€24,49
499+
€24,16
999+
€23,48
Share this product
Description
Description
|
SKF Thrust Ball Thrust Bearings: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 60mm
- Outside Diameter:
- 85mm
- Width:
- 17mm
Technical
Technical
| d | 60mm |
|---|---|
| D | 85mm |
| H | 17mm |
| Dynamic load C | 41.6 kN |
| Static load Co | 122 kN |
| Fatigue load limit Pu | 4.55 kN |
| Minimum load factor A | 0.077 |
| Reference speed | 3600 rpm |
| Limiting speed | 5000 rpm |
| Weight | 0.2 kg |
| d1 | 85mm |
| D1 | 62mm |
| r1r2 min | 1mm |
| da min | 75mm |
| Da max | 70mm |
| ra max | 1mm |
