53208 Budget Single Thrust Ball Bearing with Spherical Housing Seat U208 40x68x23mm
53208 Budget Single Thrust Ball Bearing with Spherical Housing Seat U208 40x68x23mm
Regular price
€35,36
ex VAT
Regular price
Sale price
€35,36
ex VAT
In stock
Price Break
10+
€26,93
19+
€25,42
29+
€25,11
39+
€24,81
49+
€24,51
74+
€24,20
99+
€22,69
199+
€22,39
249+
€22,09
499+
€21,78
999+
€21,18
Share this product
Description
Description
|
Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 40mm
- Outside Diameter:
- 68mm
- Width:
- 23mm
Technical
Technical
| d | 40mm |
|---|---|
| D | 68mm |
| H1 | 23mm |
| Dynamic load C | 46.8 kN |
| Static load Co | 106 kN |
| Fatigue load limit Pu | 4 kN |
| Minimum load factor A | 0.058 |
| Reference speed | 3800 rpm |
| Limiting Speed | 5300 rpm |
| Weight | 0.35 kg |
| Seating Washer | U208 |
| d1 | 68mm |
| D1 | 42mm |
| D2 | 55mm |
| D3 | 72mm |
| H | 20.3mm |
| C | 7mm |
| R | 56mm |
| s | 28.5mm |
| r1r2 min | 1mm |
| da max | 57mm |
| Da max | 55mm |
| ra max | 1mm |
