SKU: 53310?EU
53310 Budget Single Thrust Ball Bearing with Spherical Housing Seat U310 50x95x37mm
53310 Budget Single Thrust Ball Bearing with Spherical Housing Seat U310 50x95x37mm
Regular price
€80,35
ex VAT
Regular price
Sale price
€80,35
ex VAT
In stock
Price Break
10+
€61,19
19+
€57,76
29+
€57,07
39+
€56,38
49+
€55,69
74+
€55,01
99+
€51,57
199+
€50,88
249+
€50,19
499+
€49,51
999+
€48,13
Share this product
Description
Description
|
Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 50mm
- Outside Diameter:
- 95mm
- Width:
- 37mm
Technical
Technical
| d | 50mm |
|---|---|
| D | 95mm |
| H1 | 37mm |
| Dynamic load C | 88.4 kN |
| Static load Co | 190 kN |
| Fatigue load limit Pu | 6.95 kN |
| Minimum load factor A | 0.19 |
| Reference speed | 2600 rpm |
| Limiting Speed | 3600 rpm |
| Weight | 1.2 kg |
| Seating Washer | U310 |
| d1 | 95mm |
| D1 | 52mm |
| D2 | 72mm |
| D3 | 100mm |
| H | 34.3mm |
| C | 11mm |
| R | 72mm |
| s | 28mm |
| r1r2 min | 1.1mm |
| da max | 77mm |
| Da max | 72mm |
| ra max | 1mm |
