SKU: 53311?SKF
SKF 53311 Single Thrust Ball Bearing with Spherical Housing Seat U311 55x105x42mm
SKF 53311 Single Thrust Ball Bearing with Spherical Housing Seat U311 55x105x42mm
Regular price
€279,31
ex VAT
Regular price
Sale price
€279,31
ex VAT
In stock
Price Break
10+
€212,72
19+
€200,77
29+
€198,38
39+
€195,98
49+
€193,59
74+
€191,20
99+
€179,25
199+
€176,86
249+
€174,47
499+
€172,08
999+
€167,30
Share this product
Description
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 55mm
- Outside Diameter:
- 105mm
- Width:
- 42mm
Technical
Technical
| d | 55mm |
|---|---|
| D | 105mm |
| H1 | 42mm |
| Dynamic load C | 104 kN |
| Static load Co | 224 kN |
| Fatigue load limit Pu | 8.3 kN |
| Minimum load factor A | 0.26 |
| Reference speed | 2200 rpm |
| Limiting speed | 3200 rpm |
| Weight | 1.68 kg |
| Seating washer | U311 |
| d1 | 105mm |
| D1 | 57mm |
| D2 | 80mm |
| D3 | 110mm |
| H | 39.3mm |
| C | 11.5mm |
| R | 80mm |
| s | 30mm |
| r1r2 min | 1.1mm |
| da max | 85mm |
| Da max | 80mm |
| ra max | 1mm |
