SKU: 53312?EU
53312 Budget Single Thrust Ball Bearing with Spherical Housing Seat U312 60x110x42mm
53312 Budget Single Thrust Ball Bearing with Spherical Housing Seat U312 60x110x42mm
Regular price
€121,34
ex VAT
Regular price
Sale price
€121,34
ex VAT
In stock
Price Break
10+
€92,41
19+
€87,22
29+
€86,18
39+
€85,14
49+
€84,10
74+
€83,06
99+
€77,87
199+
€76,83
249+
€75,79
499+
€74,76
999+
€72,68
Share this product
Description
Description
|
Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 60mm
- Outside Diameter:
- 110mm
- Width:
- 42mm
Technical
Technical
| d | 60mm |
|---|---|
| D | 110mm |
| H1 | 42mm |
| Dynamic load C | 101 kN |
| Static load Co | 224 kN |
| Fatigue load limit Pu | 8.3 kN |
| Minimum load factor A | 0.26 |
| Reference speed | 2200 rpm |
| Limiting Speed | 3000 rpm |
| Weight | 1.71 kg |
| Seating Washer | U312 |
| d1 | 110mm |
| D1 | 62mm |
| D2 | 85mm |
| D3 | 115mm |
| H | 38.3mm |
| C | 11.5mm |
| R | 90mm |
| s | 41mm |
| r1r2 min | 1.1mm |
| da max | 90mm |
| Da max | 85mm |
| ra max | 1mm |
