53317 Budget Single Thrust Ball Bearing with Spherical Housing Seat U317 85x150x58mm
53317 Budget Single Thrust Ball Bearing with Spherical Housing Seat U317 85x150x58mm
Regular price
€285,97
ex VAT
Regular price
Sale price
€285,97
ex VAT
In stock
Price Break
10+
€217,79
19+
€205,56
29+
€203,11
39+
€200,66
49+
€198,21
74+
€195,77
99+
€183,53
199+
€181,09
249+
€178,64
499+
€176,19
999+
€171,30
Share this product
Description
Description
|
Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 85mm
- Outside Diameter:
- 150mm
- Width:
- 58mm
Technical
Technical
| d | 85mm |
|---|---|
| D | 150mm |
| H1 | 58mm |
| Dynamic load C | 190 kN |
| Static load Co | 465 kN |
| Fatigue load limit Pu | 16 kN |
| Minimum load factor A | 1.1 |
| Reference speed | 1600 rpm |
| Limiting Speed | 2200 rpm |
| Weight | 4.35 kg |
| Seating Washer | U317 |
| d1 | 150mm |
| D1 | 88mm |
| D2 | 115mm |
| D3 | 155mm |
| H | 53.1mm |
| C | 17.5mm |
| R | 112mm |
| s | 43mm |
| r1r2 min | 1.5mm |
| da max | 124mm |
| Da max | 115mm |
| ra max | 1.5mm |
