SKU: 6311/VA201-SKF
SKF 6311VA201 Single Row Deep Groove Ball Bearing High Temperature Type 55x120x29mm
SKF 6311VA201 Single Row Deep Groove Ball Bearing High Temperature Type 55x120x29mm
Regular price
€154,20
ex VAT
Regular price
Sale price
€154,20
ex VAT
In stock
Price Break
10+
€117,44
19+
€110,84
29+
€109,52
39+
€108,20
49+
€106,88
74+
€105,56
99+
€98,96
199+
€97,65
249+
€96,33
499+
€95,01
999+
€92,37
Share this product
Description
Description
|
SKF VA201 Series High Temperature Bearings: Supplied as an open type bearing are designed for high temperatures up to + 250 degrees Celsius and down to - 40 degrees Celsius. At temperatures over + 200 dry lubrication pertains. Designed for speeds up to 100rpm without maintenance. Internal clearance is C5 and all have a BLACK PHOSPHATED COATING Benefits: High temperature resilience, low maintenance |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 55mm
- Outside Diameter:
- 120mm
- Width:
- 29mm
- Seals / Shields:
- None
- Clearance:
- * Standard
Technical
Technical
| d | 55mm |
|---|---|
| D | 120mm |
| B | 29mm |
| d1 | 75.3mm |
| D2 | 104mm |
| r1r2 | 2mm |
| Basic load rating Co | 45 kN |
| Weight | 1.35 kg |
| Max operating temp | +250 deg C |
| Min operating temp | -40 deg C |
| Recommended max speed | 100 rpm |
