SKU: BR.182620
BR182620 Machined Type Imperial Needle Roller Bearing Without Inner Ring 1-1/8x1-5/8x1-1/4 inch
BR182620 Machined Type Imperial Needle Roller Bearing Without Inner Ring 1-1/8x1-5/8x1-1/4 inch
Regular price
€16,91
ex VAT
Regular price
Sale price
€16,91
ex VAT
Equivalent to: HJ182620 HJ-182620 MR18 MR-18 SJ7215 NCS1820
In stock
Price Break
10+
€15,05
19+
€14,20
29+
€14,04
39+
€13,87
49+
€13,70
74+
€13,53
99+
€12,68
199+
€12,51
249+
€12,34
499+
€12,18
999+
€11,84
Couldn't load pickup availability
Description
Description
|
Imperial Machined Type Needle Roller with Flanges: Supplied without the inner ring for instances where a mating bearing surface already exists or an inner ring is to be used & has the benefit of flanges in the outer race to compensate for small misalignments and small side loads. Benefits: Economical replacement, needles are retained within machined flange of the outer race. |
Equivalent: HJ182620 HJ-182620 MR18 MR-18 SJ7215 NCS1820
- Brand / Quality:
- IKO - High Quality
- Inside Diameter:
- 28.58mm = 1.125 (1-1/8) inch
- Outside Diameter:
- 41.28mm = 1.625 (1-5/8) inch
- Width:
- 31.75mm = 1.25 (1-1/4) inch
Technical
Technical
| Fw | 1-1/8 inch |
|---|---|
| D | 1-5/8 inch |
| C | 1-1/4 inch |
| Dynamic Load Cor | 43200 N |
| Static Load Cr | 65600 N |
| Weight | 0.128 kg |
