SKU: FYT3/4RM-SKF
SKF FYT3/4RM Oval Cast Housing with Grub Screw 3/4 inch Insert
SKF FYT3/4RM Oval Cast Housing with Grub Screw 3/4 inch Insert
Regular price
€36,11
ex VAT
Regular price
Sale price
€36,11
ex VAT
In stock
Price Break
10+
€27,50
20+
€25,96
30+
€25,65
40+
€25,34
50+
€25,03
75+
€24,72
100+
€23,18
200+
€22,87
250+
€22,56
500+
€22,25
1000+
€21,63
Description
Description
|
SKF Oval Flanged Y-bearing Units with Cast Housing and Grub Screws: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 19.05mm = 0.75 (3/4) inch
- Style:
- FYT
- Bolt Hole Centres:
- 89.7mm
Technical
Technical
| d | 3/4 inch |
|---|---|
| A1 | 24.6mm |
| A2 | 11.1mm |
| B | 25.5mm |
| H | 111.9mm |
| J | 89.7mm |
| L | 60.5mm |
| N | 11.1mm |
| G | 10mm |
| s1 | 18.3mm |
| T | 32.6mm |
| Static load Cr | 6.55 kN |
| Dynamic load Cor | 12.7 kN |
| Fatigue load limit | 0.28 kN |
| Limiting speed | 8500 rpm |
| Weight | 0.47 kg |
| Housing | Insert |
