SKF FYTB40TF Oval Cast Housing with Grub Screw 40mm Insert
SKF FYTB40TF Oval Cast Housing with Grub Screw 40mm Insert
Regular price
€57,91
ex VAT
Regular price
Sale price
€57,91
ex VAT
In stock
Price Break
10+
€51,54
19+
€48,64
29+
€48,07
39+
€47,49
49+
€46,91
74+
€46,33
99+
€43,43
199+
€42,85
249+
€42,27
499+
€41,70
999+
€40,54
Couldn't load pickup availability
Description
Description
|
SKF Oval Flanged Y-bearing Units with Cast Housing: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 40mm
- Style:
- FYTB
- Bolt Hole Centres:
- 143.5mm
Technical
Technical
| d | 40mm |
|---|---|
| A1 | 38.5mm |
| A2 | 14mm |
| B | 49.2mm |
| Da | 88.9mm |
| H | 171.5mm |
| J | 143.5mm |
| L | 102mm |
| N | 14mm |
| G | 12mm |
| s1 | 30.2mm |
| T | 54.2mm |
| Static load Cr | 19 kN |
| Dynamic load Cor | 30.7 kN |
| Fatigue load limit Pu | 0.8 kN |
| Limiting speed | 4800 rpm |
| A5 | 23.5mm |
| Weight | 1.65 kg |
| Compatible end cover closed | ECY208 |
