SKF HMV10E Metric Hydraulic Nut M50x1.5 Thread
SKF HMV10E Metric Hydraulic Nut M50x1.5 Thread
Regular price
€1.080,59
ex VAT
Regular price
Sale price
€1.080,59
ex VAT
In stock
Price Break
10+
€961,73
19+
€907,70
29+
€896,89
39+
€886,08
49+
€875,28
74+
€864,47
99+
€810,44
199+
€799,64
249+
€788,83
499+
€778,02
999+
€756,41
Couldn't load pickup availability
Description
Description
|
SKF HMV..E Series Hydraulic Nut: Mounting bearings on tapered seatings can be a difficult and time-consuming job. Using an SKF Hydraulic Nut facilitates easy and quick application of the high drive-up forces required for mounting bearings. Dismounting bearings mounted on either adapter or withdrawal sleeves is also often a difficult and time-consuming job. These problems can be reduced with the use of an SKF Hydraulic Nut. Oil is pumped into the nut and the piston is pushed out with a force, which is sufficient to free the sleeve. Benefits: Quick connection coupling can be fitted on the face or side of the nut, allowing the nut to be used in areas where space is limited. Note: A spare set of piston seals and maintenance kit is supplied as standard. |
- Brand / Quality:
- SKF - High Quality
Technical
Technical
| G Thread | M50x1.5 |
|---|---|
| d1 | 50.5 |
| d2 | 104mm |
| d3 | 114mm |
| B | 38mm |
| B1 | 4mm |
| Permitted piston displacement | 5mm |
| Piston area | 2900mm2 |
