SKU: MFC2.15/16-RHP

RHP MFC2-15/16 Four Bolt Round Cast Iron Flanged Bearing Unit and 2-15/16 inch Insert

RHP MFC2-15/16 Four Bolt Round Cast Iron Flanged Bearing Unit and 2-15/16 inch Insert
Regular price €370,19 ex VAT
Regular price Sale price €370,19 ex VAT
Sale Sold out

In stock

Price Break
10+ €281,94
20+ €266,10
30+ €262,93
40+ €259,76
50+ €256,59
75+ €253,43
100+ €237,59
200+ €234,42
250+ €231,25
500+ €228,08
1000+ €221,75
Quantity
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
Bore 2-15/16 inch
L 8.748 inch
H 6.375 inch
J 7.5 inch
G 0.625 inch
A1 2 inch
A4 0.657 inch
A5 0.5 inch
B 3.25 inch
s 1.314 inch
d1 3.878 inch
Dynamic load 71500 N
Static load 54500 N
Rec max speed 2150 rpm
Weight 5.4 kg
Insert <a href="advanced_search_result.php?keywords=1080-2-15/16G+insonly">1080-2-15/16G Click Here</a>
Casting group 9
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
