SKU: NAO15x32x12-EU
NAO15x32x12 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve
NAO15x32x12 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve
Regular price
€25,88
ex VAT
Regular price
Sale price
€25,88
ex VAT
In stock
Price Break
10+
€19,71
19+
€18,61
29+
€18,38
39+
€18,16
49+
€17,94
74+
€17,72
99+
€16,61
199+
€16,39
249+
€16,17
499+
€15,95
999+
€15,51
Description
Description
|
Budget Flange-less Needle Roller: The flange-less design permits separation of the supplied inner ring and the outer bearing to facilitate ease of mounting. Benefits: Separable, ease of mounting. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 15mm
- Outside Diameter:
- 32mm
- Width:
- 12mm
Technical
Technical
| d | 15mm |
|---|---|
| D | 32mm |
| B | 12mm |
| Dynamic load C | 12800 N |
| Static load Co | 16300 N |
| Fatigue load limit Pu | 1960 N |
| Speed in grease | 13000 rpm |
| Speed in oil | 19000 rpm |
| E | 26mm |
| F | 20mm |
| r1r2 min | 0.3mm |
| S (axial disp) | 0.5mm |
| da | 25.6mm |
| db | 19.5mm |
| Da | 26.5mm |
| Db | 20.6mm |
| ra max | 0.3mm |
| Weight | 50 g |
