SKU: NAO30x45x26-EU
NAO30x45x26 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve
NAO30x45x26 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve
Regular price
€26,69
ex VAT
Regular price
Sale price
€26,69
ex VAT
In stock
Price Break
10+
€20,33
19+
€19,19
29+
€18,96
39+
€18,73
49+
€18,50
74+
€18,28
99+
€17,13
199+
€16,90
249+
€16,68
499+
€16,45
999+
€15,99
Description
Description
|
Budget Flange-less Needle Roller: The flange-less design permits separation of the supplied inner ring and the outer bearing to facilitate ease of mounting. Benefits: Separable, ease of mounting. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 30mm
- Outside Diameter:
- 45mm
- Width:
- 26mm
Technical
Technical
| d | 30mm |
|---|---|
| D | 45mm |
| B | 26mm |
| Dynamic load C | 26400 N |
| Static load Co | 56000 N |
| Fatigue load limit Pu | 6550 N |
| Speed in grease | 8000 rpm |
| Speed in oil | 12000 rpm |
| E | 40mm |
| F | 35mm |
| r1r2 min | 0.3mm |
| S (axial disp) | 0.8mm |
| da | 39.4mm |
| db | 34.5mm |
| Da | 40.5mm |
| Db | 35.6mm |
| ra max | 0.3mm |
| Weight | 160 g |
