SKU: NAO70x100x30-EU
NAO70x100x30 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve
NAO70x100x30 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve
Regular price
€85,25
ex VAT
Regular price
Sale price
€85,25
ex VAT
In stock
Price Break
10+
€64,93
19+
€61,28
29+
€60,55
39+
€59,82
49+
€59,09
74+
€58,36
99+
€54,71
199+
€53,98
249+
€53,25
499+
€52,52
999+
€51,07
Description
Description
|
Budget Flange-less Needle Roller: The flange-less design permits separation of the supplied inner ring and the outer bearing to facilitate ease of mounting. Benefits: Separable, ease of mounting. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 70mm
- Outside Diameter:
- 100mm
- Width:
- 30mm
Technical
Technical
| d | 70mm |
|---|---|
| D | 100mm |
| B | 30mm |
| Dynamic load C | 68200 N |
| Static load Co | 176000 N |
| Fatigue load limit Pu | 22000 N |
| Speed in grease | 3600 rpm |
| Speed in oil | 5000 rpm |
| E | 88mm |
| F | 80mm |
| r1r2 min | 1mm |
| S (axial disp) | 1mm |
| da | 87.2mm |
| db | 79.3mm |
| Da | 89mm |
| Db | 81mm |
| ra max | 1mm |
| Weight | 850 g |
