SKU: SY60TF/VA201-SKF
SKF SY60TFVA201 Y Type Two Bolt Pillow Block Housing with Steel Cage Insert for Metric Shaft 60mm
SKF SY60TFVA201 Y Type Two Bolt Pillow Block Housing with Steel Cage Insert for Metric Shaft 60mm
Regular price
€446,09
ex VAT
Regular price
Sale price
€446,09
ex VAT
In stock
Price Break
10+
€339,74
19+
€320,65
29+
€316,83
39+
€313,02
49+
€309,20
74+
€305,38
99+
€286,29
199+
€282,48
249+
€278,66
499+
€274,84
999+
€267,21
Share this product
Description
Description
|
SKF High Temperature Housings and Bearing Inserts: VA201 have a grey cast iron housing and have steel cages, they are lubricated with a polyalkylene glycol/graphite mixture and can be used at temperatures from -40 deg to +250 deg Celsius, at prolonged use over 200 deg Celsius dry lubricant pertains. All versions are characterised by their BLACK PHOSPHATED COATING on the inserts.They have a max rotational speed of 100 rpm Benefits:High temp tolerance from -40 to +250 deg Celsius |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 60mm
- Temperature Range:
- High Temp
Technical
Technical
| d | 60mm |
|---|---|
| A | 60mm |
| B | 65.1mm |
| H | 139.7mm |
| H1 | 69.9mm |
| H2 | 26mm |
| J | 190.5mm |
| L | 240mm |
| N | 29mm |
| N1 | 18mm |
| G | 16mm |
| S1 | 39.7mm |
| Dynamic load C | 52.7 kN |
| Static load Co | 36 kN |
| Weight | 4.5 kg |
