SKU: UCPX.10-32
UCPX10-32 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 2 inch Bore Insert
UCPX10-32 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 2 inch Bore Insert
Regular price
€53,72
ex VAT
Regular price
Sale price
€53,72
ex VAT
Equivalent to: MP2
In stock
Price Break
10+
€47,81
19+
€45,12
29+
€44,59
39+
€44,05
49+
€43,51
74+
€42,98
99+
€40,29
199+
€39,75
249+
€39,22
499+
€38,68
999+
€37,60
Couldn't load pickup availability
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Equivalent: MP2
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 50.8mm = 2 inch
- Style:
- UCPX
- Bolt Hole Centres:
- 171mm
Technical
Technical
| d | 2 inch |
|---|---|
| h | 63.5mm |
| a | 241mm |
| e | 171mm |
| b | 73mm |
| s2 | 36mm |
| s1 | 20mm |
| g | 27mm |
| w | 126mm |
| B1 | 55.6mm |
| n | 22.2mm |
| Bolt Size | M16 |
| Weight | 4.4 kg |
| Dynamic load | 3400 kgf |
| Static load | 2550 kgf |
| Rec max speed | 3100 rpm |
